UAC-B134-ADF28MS-W | UAC-B134-ADF40MS-W | |||||||
Camera | ||||||||
Max Resolution | 4 MP | |||||||
Sensor Size | 1/1.8" CMOS | |||||||
Min. Illumination | 0.0005 lux (F1.0, AGC ON) 0 lux (white light on) | |||||||
Lens | ||||||||
Focus | 2.8 mm | 4.0 mm | ||||||
Lens Mount | M16 | |||||||
Angle of View (H) | 105.9° | 89.5° | ||||||
Angle of View (V) | 57.1° | 48.0° | ||||||
Angle of View (D) | 125.0° | 105.9° | ||||||
Illuminator | ||||||||
Illuminator Number | Two white-light illuminators | |||||||
Illumination Distance | 40m | |||||||
Lifetime | ≥ 60000 hours | |||||||
Video | ||||||||
Resolution | 4MP: 2560 (H) × 1440 (V) 1080P: 1920 (H) × 1080 (V) | |||||||
Frame Rate | CVI: 4MP@25fps (default), 4MP@30fps,1080P@25fps, 1080P@30fps AHD: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps TVI: 4MP@15fps, 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVBS: PAL, NTSC | |||||||
Shutter Time | PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s | |||||||
Image | ||||||||
Exposure Mode | Four modes: Global (default), BLC, HLC, WDR | |||||||
Day/Night | 24/7 color images | |||||||
Digital Noise Reduction | 2D/3D | |||||||
White Balance | Two modes: Auto (default), Manual | |||||||
WDR | 120 dB WDR | |||||||
Flip | Supports 180°horizontal flip, 180°vertical flip | |||||||
Digital Defog | N/A | |||||||
Audio | ||||||||
Built-in Mic | Support | |||||||
Camera Audio | CVI: 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps | |||||||
Interface | ||||||||
Power Interface | 5.5 mm Power Interface | |||||||
Video Output | BNC, supports TVI/AHD/CVI/CVBS | |||||||
Operating Environment | ||||||||
Temperature | -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉) | |||||||
Humidity | ≤ 95% RH (non-condensing) | |||||||
Surge Protection | 4kV for power&4kV for video output interfaces | |||||||
General | ||||||||
Power | DC 12 V ± 25% | |||||||
Power Consumption | MAX 6.8W | |||||||
Mount | Corner Mount&Pole Mount | |||||||
Dimensions | 206mm*73mm*73mm (L*W*H) | |||||||
Material | Graphene + Metal | |||||||
Weight | 463g(1.02lb) |
