CAB-LC3100B-E1-IN | ||||||||
Cable | ||||||||
Product model | CAB-LC3100B-E1-IN | |||||||
Product specification | HSYV-6 4×2×0.49 | |||||||
Test Standard | Fluke Test 90m | |||||||
Packing length | 305±1 m | |||||||
Rip-cord | Yes | |||||||
Seperator | Yes | |||||||
Ambient temperature | -20℃~75℃ | |||||||
Conductor | ||||||||
Material | Solid-Bare Copper | |||||||
AWG | 24 | |||||||
Nom.O.D.(mm) | 0.49±0.01 mm | |||||||
DC resistance | ≤98 Ω/km | |||||||
Insulation | ||||||||
Material | HDPE | |||||||
Diameter | 0.89±0.05 mm | |||||||
Color | Blue/White- Blue,Green/White-Green,Orange/White-Orange,Brown/White-Brown | |||||||
Sheath | ||||||||
Material | PVC | |||||||
External O.D. | 5.6±0.3 mm | |||||||
Thickness | 0.55±0.1 mm | |||||||
Tensile strength | >13.8 Mpa | |||||||
Color | Orange | |||||||
Surface Printing | ||||||||
Letter height | 3.0±0.3 mm | |||||||
Print error / Space | 1±0.005 m | |||||||
Color | Black | |||||||
Packing | ||||||||
Packing | Pallet | |||||||
Once packing dimension | 420mm*205mm*420mm |
