| CAB-LC2100B-E1-IN | ||||||||
| Cable | ||||||||
| Product model | CAB-LC2100B-E1-IN | |||||||
| Test Standard | Fluke Test 90m | |||||||
| Product specification | HSYV-5e 4×2×0.43 | |||||||
| Packing length | 305±1 m | |||||||
| Rip-cord | Yes | |||||||
| Ambient temperature | -20℃~75℃ | |||||||
| Conductor | ||||||||
| Material | Solid-Bare Copper | |||||||
| AWG | 25 | |||||||
| Nom.O.D.(mm) | 0.43±0.01 mm | |||||||
| DC resistance | ≤113 Ω/km | |||||||
| Insulation | ||||||||
| Material | HDPE | |||||||
| Diameter | 0.75±0.05 mm | |||||||
| Color | Blue/White- Blue,Green/White-Green,Orange/White-Orange,Brown/White-Brown | |||||||
| Sheath | ||||||||
| Material | PVC | |||||||
| External O.D. | 4.5±0.3 mm | |||||||
| Tensile strength | >13.8 Mpa | |||||||
| Thickness | 0.5±0.1 mm | |||||||
| Color | Gray | |||||||
| Surface Printing | ||||||||
| Color | Black | |||||||
| Letter height | 3.0±0.3 mm | |||||||
| Print error / Space | 1±0.005 m | |||||||
| Packing | ||||||||
| Packing | Pallet | |||||||
| Once packing dimension | 340mm*220mm*340mm | |||||||
| Class | Date | Title | Language | Type | Preview | Download |
| Datasheet | 2025/8/26 20:57:41 | UNV CAB-LC2100B-E1-IN UTP Category 5E Cables(0.43mm).pdf | English | Preview | Download A > |
| Class | Date | Title | Type | Download |
| HD Image | 2025/10/18 3:01:53 | CAB-LC2100B-E1-IN_HD_Image_1.png | png | Download |
