| RVS441@2D-D30-OS | ||
| Channel | channel 1 | channel 2 |
| Camera | ||
| Max Resolution | 4 MP | |
| Sensor | 1/1.8" CMOS | |
| Basic Parameters | ||
| Min. Illumination | 0.0003 lux (1.0, AGC ON, color), 0 lux (warm light on) | 0.0005 lux (F1.6, AGC ON, color) , 0.0003lux (F1.6, AGC ON, black/white) |
| Shutter Range | 1 ~ 1/100000s | |
| Day/Night | Color, all day | Day : Color, Night : IR |
| Lens | ||
| Focal Length | 4.0 mm | 8 to 32 mm |
| Optical Zoom | N/A | 4X |
| Iris | F1.0 | F1.6 |
| Field of View (H) | 51.2° | 8.7° ~ 24.5° |
| Field of View (V) | 93.9° | 15.4° `~ 44.1° |
| Illuminator | ||
| Built-in Illuminator Type | 2 near warm lights + 2 mid-IR lights + 8 far-IR lights | |
| Light Beads | 12 | |
| Built-in Illumination Range | Warm light : 40m | IR light : 200m |
| Key Functional Parameters | ||
| Radar-video Fusion | Support | |
| Max. Detection Targets | 32 | |
| Max. Detection Areas | 8 | |
| Detection Target Type | Pedestrian, motor vehicle, non-motor vehicle | |
| Pedestrian Detection Capability | Accurate recognition of various actions, including walking, crawling, crouching, running, and wall climbing | |
| Detection Direction | Supports incoming, outgoing, lateral motion detection | |
| Detection Distance Range | 10 ~ 300 m | |
| Lateral Detection Range | 20 ~ 200 m | |
| Radar | ||
| Radar Frequency Band | 80GHz | |
| Modulated Waveform | FMCW | |
| Detection Frequency | Up to 16 times per second | |
| Distance Resolution | 1.5m | |
| Speed Resolution | 0.1m/s | |
| Speed Measurement Range | 0.03-30m/s | |
| Azimuth Angle Precision | ±1° | |
| Distance Precision | ±0.75m | |
| Speed Precision | ±0.2m/s | |
| Detection Angle | Horizontal Angle ±8° Elevation Angle ±3 | |
| Video | ||
| Video Compression | H.265, H.264, MJPEG | |
| Video Resolution | Main stream: 2688×1520, 1080P, 720P, D1, 2CIF, CIF Sub stream: 1080P, 720P, D1, 2CIF, CIF Third stream: D1, 2CIF, CIF | |
| Video Frame Rate | 2688×1520@30 fps | |
| Video Bit Rate | 128-16384Kbps | |
| Video OSD | Multiple types of contents, such as date and time, with custom font color | |
| Image | ||
| Image Resolution | 2688×1520 | |
| Image Encoding Format | JPEG | |
| Image Settings | Exposure mode, shutter time, gain, exposure compensation, day/night mode, etc. | |
| Digital Noise Reduction | 2DNR/3DNR | |
| Event | ||
| Event Type | Intrusion detection, cross line detection | |
| Storage | ||
| Edge Storage | GB eMMC, supports expansion to 128 GB TF card | |
| Network | ||
| Protocols | SSH; RTP; RTCP; IPv4; ARP; TCP; UDP; DHCP; RTSP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; 802.1x; SNMP; LAPI | |
| Compatible Integration | ONVIF | |
| Interface | ||
| Network Interface | 1 x 10M/100M/1000M Ethernet interface | |
| Serial Port | 1 x RS 485 | |
| Alarm Input | 2 | |
| Alarm Output | 2 | |
| Reset Button | Support | |
| General | ||
| Power Supply | DC 24V ±25% | |
| Power Consumption | ≤ 30W | |
| Dimensions | 248.5mm (W) ×142.3mm (D) ×240.0mm (H) | |
| Weight | 2.86kg (with bracket) | |
| Lightning and Surge Protection | Support | |
| Operating Temperature | - 40°C to 70°C | |
| Operating Humidity | 5% to 95% RH (non-condensing) | |
| Ingress Protection | IP67 | |
| Spirit Level | Support | |
| Compliance | ||
| NDAA Compliant | Support | |
