| PKC17C0@6-C-LP |
Camera |
Sensor | 1/1.7" 12MP CMOS |
Focal length | 1.8mm |
Shutter | 1/100000 to 1/25s |
Minimum illumination | 0.03lux |
Lens type | Fixed-focal lens |
Iris | F2.0 |
FOV | 180° |
Image |
Resolution | Main stream: 3840*2160; Sub stream: 3280*2464, 2000*2000; Third stream: 720*576 (D1), 352*288 (CIF) |
Frame rate | 20, 18, 16, 15, 12, 10, 8, 6, 5, 4, 3, 2, 1 |
Video compression | H.264 (default), H.265 |
ROI | Support, up to 8 areas |
Video OSD | Supports custom OSD on live view and image |
Image OSD | Supports custom OSD on live view and image |
Privacy mask | Support, up to 4 areas |
Interface |
Network interface | 1 x 1000M/100M/10M adaptive Ethernet copper port |
Serial port | 1 xRS485 |
Boolean output | 1 x alarm output |
Boolean input | 2 x alarm input |
Audio interface | 1 x audio output, 1 x audio input |
Built-in mic | Support |
Built-in speaker | Support |
BNC | Support |
Service Config |
Third-party server | Two photo servers via HTTP, VIID, and FTP protocols; MQTT server via MQTT protocol |
Smart |
Parking space detection | Supports detecting 6 parking spaces and recognizing 6 license plates |
Parking space detection rate | 99% |
Structure |
Indicator | 7-color LED indicator, displays the parking space status |
Mount method | Adapter panel |
General |
Power supply | DC 12V ±25%, PoE (802.3at) |
Weight | 690g |
Ingress protection | IP67 |
