PKC17C0@12-C | ||||||||
Camera | ||||||||
Sensor | 1/1.7" 12MP CMOS | |||||||
Focal length | 1.8mm | |||||||
Shutter | 1/100000 to 1/25s | |||||||
Minimum illumination | 0.03lux | |||||||
Lens type | Fixed-focal lens | |||||||
Iris | F2.0 | |||||||
FOV | 180° | |||||||
Image | ||||||||
Resolution | Main stream: 3840*2160; Sub stream: 3280*2464, 2000*2000; Third stream: 720*576 (D1), 352*288 (CIF) | |||||||
Frame rate | 20, 18, 16, 15, 12, 10, 8, 6, 5, 4, 3, 2, 1 | |||||||
Video compression | H.264 (default), H.265 | |||||||
ROI | Support, up to 8 areas | |||||||
Video OSD | Supports custom OSD on live view and image | |||||||
Image OSD | Supports custom OSD on live view and image | |||||||
Privacy mask | Support, up to 4 areas | |||||||
Interface | ||||||||
Network interface | 1 x 1000M/100M/10M adaptive Ethernet copper port | |||||||
Serial port | 1 xRS485 | |||||||
Boolean output | 1 x alarm output | |||||||
Boolean input | 2 x alarm input | |||||||
Audio interface | 1 x audio output, 1 x audio input | |||||||
Built-in mic | Support | |||||||
Built-in speaker | Support | |||||||
BNC | Support | |||||||
Service Config | ||||||||
Third-party server | Two photo servers via HTTP, VIID, and FTP protocols; MQTT server via MQTT protocol | |||||||
Smart | ||||||||
Parking space detection | Supports detecting 12 parking spaces | |||||||
Parking space detection rate | 99% | |||||||
Structure | ||||||||
Indicator | 7-color LED indicator, displays the parking space status | |||||||
Mount method | Adapter panel | |||||||
General | ||||||||
Power supply | DC 12V ±25%, PoE (802.3at) | |||||||
Weight | 690g | |||||||
Ingress protection | IP67 |
