| HC191-GI-1640-OS | ||||||||
| Camera | ||||||||
| Sensor | 1.1" 9MP Global Shutter CMOS | |||||||
| Max. Resolution | 4096 × 2160 | |||||||
| Min. Illumination | 0.001 Lux | |||||||
| Shutter Time | 50 us to 20000 us | |||||||
| Day/Night | ICR auto switch: Uses IR cut-off filter (IRCF) with polarizer in the daytime, and uses ordinary filter at night | |||||||
| Lens | ||||||||
| Lens Type | Motorized varifocal lens, 16-40 mm (built-in) | |||||||
| Max. Aperture | F1.5 | |||||||
| Iris Type | P-iris | |||||||
| Field of View(H) | 50.1° to 21.2° | |||||||
| Field of View (V) | 34.4° to 14.7° | |||||||
| Field of View (D) | 60.3° to 25.3° | |||||||
| Focus | Motorized | |||||||
| Zoom | Motorized | |||||||
| Illuminato | ||||||||
| Built-in Illuminator Type | IR light | |||||||
| Light Beads | 3 | |||||||
| Built-in Illumination Range | Up to 30 m | |||||||
| External Illuminator | Infrared strobe light; All-in-one light (infrared flash & white flash & infrared strobe) | |||||||
| Video | ||||||||
| Video Compression | H.265, H.264, MJPEG | |||||||
| Video Resolution | Main stream: 4096×2160, 1920×1080, 1600×1200, 1280×720 Sub stream: 1920×1080, 1280×720, 720×576, 704×288, 352×288 Third stream: 720×576, 704×288, 352×288 | |||||||
| Video Frame Rate | 4096×2160@50 fps 3840×2336@50 fps | |||||||
| Video Bit Rate | 128-16384 Kbps | |||||||
| Video OSD | Up to 8 OSDs | |||||||
| ROI | Up to 8 ROIs | |||||||
| Image | ||||||||
| Composite Image | Supports merging up to 4 violation images into a single composite image | |||||||
| Image Resolution | 4096 × 2160 | |||||||
| Image Encoding Format | JPEG | |||||||
| Image Settings | Shutter, gain, white balance | |||||||
| Digital Noise Reduction | 2DNR/3DNR | |||||||
| Image OSD | Supports various overlays with adjustable overlay position, overlay order, font size, font style, font color, etc. | |||||||
| Intelligent | ||||||||
| Lane Coverage | Up to 3 lanes (depends on lens type) | |||||||
| Vehicle Detection Mode | Radar (external radar) , video | |||||||
| Target Detection | Motor vehicle, motorcycle | |||||||
| ANPR | Supports plate recognition Support speed measurement Supports vehicle attributes: vehicle type, vehicle color, vehicle brand, plate color (customization) Supports speeding detection (external radar required) | |||||||
| Speed Capture Range | 5 km/h–300 km/h (external radar required) | |||||||
| Vehicle Type Recognition | 10 types: Car/Van/Large Bus/Medium Bus/Heavy Truck/Light Truck/SUV/MPV/Pickup/Motorcycle | |||||||
| Vehicle Color Recognition | 12 colors: Red, Yellow, green, blue, purple, pink, brown, white, Grey, black, silver, orange Not available during nighttime | |||||||
| Vehicle Manufacturer Recognition | 133 Manufacturers: Audi, ALFA ROMEO, AION, ANKAI, ACURA, Aston Martin, ARCFOX, BYD, BUICK, BENTLEY, BMW, BAIC MOTOR, BUGATTI, BORGWARD, Beiben Truck,Besturn, CHANGAN, Citroën, Cadillac, CHERY, CHRYSLER, Chevrolet, CHTC, DONGFENG, DACIA, Daihatsu, DATSUN, DODGE, DS, DAEWOO, Dongnan, EXEED, FAW, Ford, FORLAND, Ferrari, FIAT, Foton, GEEL, GAC, GREAT WALL, GMC, Geometry, HONDA, HYUNDAI, HIGER, Hino, Hong Qi, Hava, Haima, INFINITI, Isuzu, IVECO, IM, JAC, JEEP, JAGUAR, JOYLONG, JMC, JETTA, JETOUR, KIA, Karry, King Long, KMULLER, LYNK&CO, LINCOLN, LEXUS, LOTUS, LANDWIND, LANDROVER, LAMBORGHINI, LIFAN, LEVC, LUXGEN, LEOPARD, LADA, LUMMA, LI AUTO, LEAPMOTOR, Mercedes-Benz, MINI, MAZDA, McLaren, MASERATI, MAN, MG, MITSUBISHI, MAXUS, MORGAN, MUSTANG, MODERN AUTO, NISSAN, NIO, OPEL, ORA, OUSHANG,PEUGEOT, PORSCHE, Polestar, QOROS, Roewe, ROLLS ROYCE, RENAULT, SINOTRUK, SXACT, SKODA, SSANGYONG, SMART, SUZUKI, SUBARU, SAAB, SCANIA, SEAT, SWM, SANY, SILVER, SKYWORTH, TOYOTA, TESLA, TANK, Volkswagen, VOLVO, VOYAH, Wuling, WEY, XCMG, Xiaopeng Motors, XINYUAN, YUTONG, ZHONGTONG, ZOTYE, ZEEKER, ZHONGHUA, ZHINUO | |||||||
| License Plate Color Recognition | Supports customization | |||||||
| Violation Capture | Captures speeding vehicles (external radar required) | |||||||
| LPR Countries/Regions | Countries/regions where license plates consist of English letters and numbers; supports customization for other countries | |||||||
| Smart-PL | Built-in | |||||||
| Storage | ||||||||
| Edge Storage | 8GB eMMC, supports expansion to 256 GB micro SD (TF) card | |||||||
| Automatic Network Replenishment (ANR) | Support, available when used with a Uniview NVR | |||||||
| Network | ||||||||
| Protocols | SSH; RTP; RTCP; IPv4; ARP; TCP; UDP; DHCP; RTSP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; 802.1x; SNMP; LAPI | |||||||
| Compatible Integration | ONVIF; SDK | |||||||
| User/Host | Up to 32 users; 3 user levels: administrator, common user, and operator | |||||||
| Security | TLS1.3; Password protection; Strong password; HTTPS encryption; Export operation logs; Basic and digest authentication for RTSP; Digest authentication for HTTP; TLS 1.2; WSSE and digest authentication for ONVIF | |||||||
| Web Browser | IE 10 or higher, Chrome 45.0 or higher, FireFox 52.0 or higher, Edge 79 or higher | |||||||
| Interface | ||||||||
| I/O control | 4 × synchronous signal output interface (switch) 4 × synchronous signal output interface (TTL) or 4 × signal input interface (switch) 1 × standard relay interface 3 × RS485, 1 × RS232 | |||||||
| Network | 2 × RJ45 10M/100M/1000M Base T adaptive Ethernet interface | |||||||
| USB | 1 USB 3.0 interface | |||||||
| Reset Button | Support | |||||||
| General | ||||||||
| Power Supply | 100-240 V AC (50 Hz/60 Hz) | |||||||
| Power Consumption | ≤ 16 W | |||||||
| Dimensions | 211.7mm (W) ×137.2mm (H)×575mm (D) | |||||||
| Weight | Approx. 5.67 kg | |||||||
| Operating Environment | - 40°C to 70°C, 10% to 90% RH (non-condensing) | |||||||
| Lightning and Surge Protection | Support, ≤ 6KV | |||||||
| Ingress Protection | IP65 | |||||||
| Material | Aluminum alloy | |||||||
| Heater | N/A | |||||||
| Fan | Support | |||||||
