DEU1016-B | ||||||||
Hard Disk | ||||||||
SATA | 16 SATA Interfaces | |||||||
Capacity | Up to 16TB for each disk | |||||||
External Interface | ||||||||
miniSAS | 1 | |||||||
RS232 | 1 | |||||||
Power Supply | AC 100~240V | |||||||
Working Environment | ||||||||
Working Temperature | -10 °C ~ + 55 °C (+14 °F ~ +131 °F) | |||||||
Working Humidity | 5%~95% RH (non-condensing) | |||||||
Power Consumption(With HDD) | < 160W(With 16 HDDs) | |||||||
Dimensions | ||||||||
Weight(Without HDD) | < 10Kg (22lb) | |||||||
Dimensions | 482mm × 477mm× 131mm (19.0"×18.8"×5.1") | |||||||
Height | 3U |
Class | Date | Title | Language | Type | Download |
Datasheet | 2024/12/13 7:07:07 | UNV DEU1016-B Disk Enclosure.pdf | English | Download |
Class | Date | Title | Type | Download |
HD Image | 10/22/2024 9:47:42 AM | DEU1016-B_HD_Image_1.png | png | Download |
HD Image | 10/22/2024 9:47:42 AM | DEU1016-B_HD_Image_2.png | png | Download |
HD Image | 10/22/2024 9:47:42 AM | DEU1016-B_HD_Image_3.png | png | Download |
Class | Date | Title | Language | Type | Download |
Quick Guide | 9/4/2024 5:38:47 AM | Quick Guide.pdf | English | Download |
Class | Date | Title | Download |
Dimensions | 10/22/2024 9:47:42 AM | DEU1016-B_Dimensions_1.png | Download |
