OER-SR42 | OER-SR12 | OER-SR22 | ||||||||||
Hardware Specification | ||||||||||||
Dimensions (L x W x H) | 235mm x 305mm x 76mm | |||||||||||
Weight | 2.3KG | 2.2KG | 2.2KG | |||||||||
Door Control | 4 doors | 1 door | 2 doors | |||||||||
Card Reader | 8 | 2 | 4 | |||||||||
Wiegand Input Interface (Max DC14V Withstand Voltage) | 8 | 2 | 4 | |||||||||
Wiegand Format | WG18/26/34/66 | |||||||||||
Relay Output | 4 sets (7A) | 1 set (7A) | 2 sets (7A) | |||||||||
Door Magnetic Port | 4 | 1 | 2 | |||||||||
Fire Module Expansion Port | 1 | |||||||||||
Operating Environment | Indoor(-10°C to +65°C) | |||||||||||
Power Supply | AC 100V to 240V(50Hz or 60Hz) | |||||||||||
Mount | Wall mount | |||||||||||
Basic Business | ||||||||||||
Communication Mode | TCP/IP | |||||||||||
Specification Index | ||||||||||||
Card Capacity | 42000 | |||||||||||
Event Capacity | 200000 |
Class | Date | Title | Language | Type | Preview | Download |
Datasheet | 3/16/2025 8:02:23 AM | UNV OER-SR12, OER-SR22, OER-SR42 OER-SR12, OER-SR22, OER-SR42 Access Controller.pdf | English | Preview | Download A > |
Class | Date | Title | Type | Download |
HD Image | 3/16/2025 3:00:41 AM | OER-SR42_HD_Image_1.png | png | Download |
HD Image | 3/16/2025 3:00:41 AM | OER-SR42_HD_Image_2.png | png | Download |
HD Image | 3/16/2025 3:00:41 AM | OER-SR42_HD_Image_3.png | png | Download |
Class | Date | Title | Language | Type | Preview | Download |
Quick Guide | 9/15/2024 5:41:48 AM | Quick Guide.pdf | English | Preview | Download A > |
Class | Date | Title | Download |
Dimensions | 3/16/2025 3:00:41 AM | OER-SR42_Dimensions_1.png | Download |
