| NSW2010-26GT2GC-POE-IN |
Hardware Specification |
Ports Type | 24×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)+2×1000Mbps ports(Combo) |
Standards | IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3az |
Switching capacity | 56 Gbps |
Forwarding performance | 41.7Mpps |
Packet Buffer | 4 M bit |
MAC | 8K |
Power supply | AC: 100-240 V, 50/60 Hz |
PoE | support POE |
Max. PoE Power | Max capacity: 370 W, Max capacity for single port: 30 W |
Cooling Fans | 2 |
Weight | <5kg |
Indicator | PWR (Green), LNK/ACT (Green), PoE (Orange) |
Dimensions (W×D×H) | 440mm x 207mm x 44mm (17.3"×8.1"×1.7")
|
Storage Temperature | -40 ℃ to 70 ℃ |
Operating temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
Storage humidity | 5%~90% (non-condensing) |
Operating humidity | 10%~90% (non-condensing) |
Working Mode | Default (Normal mode) : All ports can communicate with each other, VLAN (Secure mode): Downlink ports can communicate only with uplink ports., Extend (Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports |
