| GC-CAB5e-1m-IN | ||||||||
| Cable | ||||||||
| Product model | U /UTP CAT5e PVC Patch Cord | |||||||
| Test Standard | TIA-568.2-D, ISO/IEC 11801, RoHS 2.0 | |||||||
| Conductor | ||||||||
| Material | Bare Copper (99.95%) | |||||||
| Nom.O.D.(mm) | 7*0.16mm±0.005mm, 26AWG | |||||||
| Insulation | ||||||||
| Material | HDPE | |||||||
| Diameter | 0.80±0.05 mm | |||||||
| Sheath | ||||||||
| Material | PVC | |||||||
| Thickness | 0.5 mm±0.05mm | |||||||
| External O.D. | 4.6mm±0.3mm | |||||||
| Color | Grey (RAL7046) | |||||||
| Physical | ||||||||
| Length | 1m | |||||||
| Class | Date | Title | Language | Type | Preview | Download |
| Datasheet | 2025/8/27 7:55:33 | UNV GC-CAB5e-1m-IN UTP Patch Cord.pdf | English | Preview | Download A > |
| Class | Date | Title | Type | Download |
| HD Image | 2025/10/28 3:14:45 | GC-CAB5e-1m-IN_HD_Image_1.png | png | Download |
