IPC268EA-AHDZK-I1 | IPC268EA-AHDX4K-I1 | |||||||
Camera | ||||||||
Sensor | 1/1.8" CMOS | |||||||
Min. Illumination | Colour:0.001 lux (F1.2, AGC ON) B/W:0.0005 lux (F1.2, AGC ON) 0 lux with IR | Colour:0.003 lux (F1.6, AGC ON) B/W:0.002 lux (F1.6, AGC ON) 0 lux with IR | ||||||
Day/Night | IR-cut filter with auto switch (ICR) | |||||||
Shutter | Auto/Manual, 1 ~ 1/100000s | |||||||
WDR | 140dB | |||||||
S/N | >56dB | |||||||
Lens | ||||||||
Focal Length | 2.8 ~ 12 mm | 8 ~ 32 mm | ||||||
Optical Zoom | 4X | |||||||
Iris | F1.2 | F1.6 | ||||||
Iris Type | P-iris | |||||||
DORI | ||||||||
DORI Distance (Detect) | 108.0m(354.3ft)~180.0m(590.6ft) | 240.3m(788.4ft)~644.4m(2114.2ft) | ||||||
DORI Distance (Observe) | 43.2m(141.7ft)~72.0m(236.2ft) | 96.1m(315.4ft)~257.8m(845.7ft) | ||||||
DORI Distance (Recognize) | 21.6m(70.9ft)~36.0m(118.1ft) | 48.1m(157.7ft)~128.9m(422.8ft) | ||||||
DORI Distance (Identify) | 10.8m(35.4ft)~18.0m(59.1ft) | 24.0m(78.8ft)~64.4m(211.4ft) | ||||||
Illuminator | ||||||||
Illumination Distance (IR) | 60 m (196.9 ft) | 120 m (393.7 ft) | ||||||
IR On/Off Control | Auto/Manual | |||||||
Wavelength | 850 nm | |||||||
Video | ||||||||
Frame Rate-Main Stream | 8MP(3840*2160), Max 60fps | |||||||
Frame Rate-Sub Stream | 2MP(1920*1080), Max 60fps | |||||||
Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||||
Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) | |||||||
Video Bit Rate | 128 Kbps ~ 16 Mbps | |||||||
Frame Rate-Third Stream | D1 (720*576), Max 60fps | |||||||
ROI | Support | |||||||
Video Stream | Triple Streams | |||||||
OSD | Up to 10 OSDs | |||||||
Intelligent | ||||||||
Metadata Analyse | Support human body, , motor vehicle and non-motor vehicle image capture and attribute collection | |||||||
Recognition | : Max support 16 face libraries; Max supports 100000 faces in face library | |||||||
People Counting | Support People Flow Counting and Crowd Density Monitoring | |||||||
Exception Detection | Object Removed,Object Left Behind, Scene Change, Defocus Detection | Object Removed,Object Left Behind | ||||||
Smart Intrusion Prevention | Cross line detection, Intrusion detection, Enter area detection, Leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) | |||||||
Image | ||||||||
White Balance | Auto&Outdoor&Fine Tune&Sodium Lamp&Locked&Auto2 | |||||||
Digital Noise Reduction | 2D/3D DNR | |||||||
Smart IR | Support | |||||||
Flip | Normal&Flip Vertical&Flip Horizontal&180°&90°Clockwise&90°Anti-clockwise | |||||||
HLC | Support | |||||||
Defog | Digital Defog | |||||||
Events | ||||||||
Basic Detection | Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind, Scene Change, Defocus Detection | Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind | ||||||
General Function | Watermark&IP Address Filtering&Access Policy&ARP Protection&RTSP Authentication&User Authentication&HTTP authentication&Alarm input&Alarm output | |||||||
Audio | ||||||||
Audio Compression | G.711U&G.711A | |||||||
Audio Bitrate | 128 Kbps | |||||||
Two-way Audio | Support | |||||||
Suppression | Support | |||||||
Sampling Rate | 16KHZ | |||||||
Storage | ||||||||
Edge Storage | Micro SD, up to 512 GB | |||||||
Network Storage | ANR, NAS (NFS) | |||||||
Network | ||||||||
Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3 | |||||||
Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK | |||||||
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator | |||||||
Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS1.3 | |||||||
Client | EZStation, UNV-Link, UNV-Link Pro | |||||||
Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above&Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above | |||||||
Interface | ||||||||
Audio I/O | 2 Input: impedance 1kΩ; amplitude 2.5V [p-p], 1 Output: impedance 600Ω; amplitude 2.5V [p-p] | |||||||
Alarm I/O | 3/2 | |||||||
Serial Port | 1 channel RS485 interface | |||||||
Built-in Mic | Support, built-in mic*2 | |||||||
Built-in Speaker | Support | |||||||
Network | 1 * RJ45 10M/100M/1000M Base-TX Ethernet | |||||||
Certification | ||||||||
EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) | |||||||
Safety | CE LVD (EN 62368-1:2014+A11:2017) UL (UL 62368-1, 3rd Ed., 2021-10-22 ) | |||||||
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) | |||||||
Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) | |||||||
General | ||||||||
Power | DC12V(±25%) , PoE+ (IEEE 802.3at) | |||||||
Power Consumption | Max 16W | Max 19W | ||||||
Heater | Support | |||||||
Power Interface | Ø 5.5 mm coaxial power plug | |||||||
Dimensions | 406 x 126 x 130 mm (16.0” x 5.0” x 5.1”) (L x W x H) | |||||||
Weight | 1.92kg(4.23lb) | |||||||
Working Environment | -40 ℃ ~ 60 ℃ (-40 °F ~ 140 °F), Humidity: ≤95% RH (non-condensing) | |||||||
Surge Protection | 6KV |
