HDX4-IR-I1 | HDX4-WH-I1 | |||||||
Camera | ||||||||
Sensor | 1/1.8" CMOS | |||||||
Min. Illumination | Colour:0.003 lux (F1.6, AGC ON) B/W:0.002 lux (F1.6, AGC ON) 0 lux with IR | Colour:0.003 lux (F1.6, AGC ON) 0 lux with Light | ||||||
Day/Night | IR-cut filter with auto switch (ICR) | |||||||
Shutter | Auto/Manual, 1 ~ 1/100000s | |||||||
WDR | 140dB | |||||||
S/N | >56dB | |||||||
Lens | ||||||||
Focal Length | 8 ~ 32 mm | |||||||
Digital Zoom | 16X | |||||||
Optical Zoom | 4X | |||||||
Iris | F1.6 | |||||||
Iris Type | P-iris | |||||||
Field of View (H) | 42°~15.3° | |||||||
Field of View (V) | 22.6°~8.8° | |||||||
Field of View (D) | 51.7°~18.1° | |||||||
DORI | ||||||||
DORI Distance (Detect) | 240.3m(788.4ft)~644.4m(2114.2ft) | |||||||
DORI Distance (Observe) | 96.1m(315.4ft)~257.8m(845.7ft) | |||||||
DORI Distance (Recognize) | 48.1m(157.7ft)~128.9m(422.8ft) | |||||||
DORI Distance (Identify) | 24.0m(78.8ft)~64.4m(211.4ft) | |||||||
Illuminator | ||||||||
Illumination Distance (Warm Light) | 40 m (131.2 ft) | |||||||
Illumination Distance (IR) | 40 m (131.2 ft) | |||||||
Wavelength | 850 nm | |||||||
Video | ||||||||
Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||||
Frame Rate-Main Stream | 8MP(3840*2160), Max 60fps | |||||||
Frame Rate-Sub Stream | 2MP(1920*1080), Max 60fps | |||||||
Frame Rate-Third Stream | D1 (720*576), Max 60fps | |||||||
Frame Rate Recommendation | 3840*2160@60fps+1080P@60fps+D1@60fps | |||||||
Video Bit Rate | 128 Kbps ~ 16 Mbps | |||||||
U-code | Support | |||||||
ROI | Up to 8 areas | |||||||
Video Stream | Triple Streams | |||||||
OSD | Up to 10 OSDs | |||||||
Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) | |||||||
Image | ||||||||
White Balance | Auto,Outdoor,Fine Tune,Sodium Lamp,Locked,Auto2 | |||||||
Digital Noise Reduction | 2D/3D DNR | |||||||
Smart IR | Support | N/A | ||||||
Flip | Normal,Flip Vertical,Flip Horizontal,180°,90°Clockwise,90°Anti-clockwise | |||||||
HLC | Support | |||||||
Defog | Digital Defog | |||||||
Intelligent | ||||||||
ANPR | Up to 4 car lanes can be set: Support pedestrian, motor vehicle and non-motor vehicle image capturing; Support recognizing car license plate more accurately by choosing different country/region and attribute collection | |||||||
Supports Multiple Countries | North America: United States, CanadaEU: France, Spain, Portugal, Germany, UK, Ireland, Bulgaria, Latvia, Romania, Slovenia, Poland, Hungary, Serbia, Czech Republic, Slovakia, Bosnia and Herzegovina, Greece, Croatia, Ukraine Asia Pacific: South Korea, Indonesia, Malaysia, SingaporeMiddle East: Iraq, Saudi Arabia, United Arab Emirates | |||||||
Events | ||||||||
Basic Detection | Motion detection,Audio detection,Tampering alarm | |||||||
General Function | Watermark,IP Address Filtering,Access Policy,ARP Protection,RTSP Authentication,User Authentication,HTTP authentication,Alarm input,Alarm output | |||||||
Audio | ||||||||
Audio Compression | G.711U,G.711A | |||||||
Audio Bitrate | 128 Kbps | |||||||
Two-way Audio | Support | |||||||
Suppression | Support | |||||||
Sampling Rate | 16KHZ | |||||||
Storage | ||||||||
Edge Storage | Micro SD, up to 512 GB | |||||||
Network Storage | ANR,NAS(NFS) | |||||||
Network | ||||||||
Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3 | |||||||
Compatible Integration | API,SDK,ONVIF (Profile S, Profile G, Profile T) | |||||||
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator | |||||||
Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS1.3 | |||||||
Client | EZStation, UNV-Link, UNV-Link Pro | |||||||
Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above | |||||||
Interface | ||||||||
Audio I/O | 2/1 | |||||||
Alarm I/O | 3/2 | |||||||
Serial Port | 1 channel RS485 interface | |||||||
Built-in Mic | Support, built-in mic*2 | |||||||
Built-in Speaker | Support | |||||||
Network | 1 * RJ45 10M/100M/1000M Base-TX Ethernet | |||||||
Certification | ||||||||
EMC | CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 61000-3-3:2013+A1:2019+A2:2021,EN IEC 61000-3-2: 2019+A1: 2021, EN 50130-4:2011+A1:2014) FCC (FCC CFR 47 part15 B, ANSI C63.4 2014) | |||||||
Safety | EN IEC 62368-1:2020+A11:2020 UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01 ) | |||||||
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) | |||||||
Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) | |||||||
General | ||||||||
Power | DC12V(±25%) , PoE+ (IEEE 802.3at) | |||||||
Power Consumption | Max 18W | Max 22W | ||||||
Power Interface | Ø 5.5 mm coaxial power plug | |||||||
Dimensions | 406 x 125 x 130mm(16.0” x 4.9” x 5.1”) | |||||||
Weight | 1.86Kg(4.10lb) | |||||||
Working Environment | -40℃ ~ 70℃ (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) | |||||||
Surge Protection | 6KV |
