HC191@GI-OS | ||||||||
Camera | ||||||||
Sensor | 1.1’’ 9MP Global Shutter CMOS | |||||||
Min. illumination | Color: 0.001 Lux, 0.0005 Lux with IR | |||||||
Image settings | Shutter, gain, white balance, WDR | |||||||
Image/video | ||||||||
Acquisition format | 4096×2160@50fps | |||||||
Video compression | Video compression H.265, H.264, MJPEG | |||||||
Frame rate | Up to 50fps | |||||||
Image resolution | 4096x2160 | |||||||
Video resolution | Main stream: 4096×2160, 1920×1080, 1600×1200, 1280×720 Sub stream: 4096×2160, 1920×1080, 1600×1200, 1280×720, 720×576, 704×288, 352×288 Third stream: 720×576, 704×288, 352×288 | |||||||
Video OSD | Supports various overlays such as date and time with adjustable font size, font style, font color, etc. | |||||||
Image OSD | Supports various overlays with adjustable overlay position, overlay order, font size, font style, font color, etc. | |||||||
ROI | Supports up to 8 ROIs | |||||||
Functions | ||||||||
Vehicle detection mode | Radar, video | |||||||
Illumination type | Built-in strobe light with adjustable brightness Optional external all-in-one light (infrared flash & white flash & infrared strobe) | |||||||
Image composition | Image composition Support | |||||||
Image size | Adjustable | |||||||
Smart-PL | Built-in | |||||||
Interface | ||||||||
I/O control | 4 × synchronous signal output interface (switch) 8 × synchronous signal output interface (TTL) 8 × signal input interface (switch) 2 × standard relay interface Control interface: 4 × RS485, 1 × RS232 | |||||||
Network | 2 × RJ45 10M/100M/1000M Base T adaptive Ethernet interface | |||||||
Reset button | 1 | |||||||
Storage | ||||||||
Front-end storage | 32GB eMMC, supports up to 256G micro SD (TF) card expansion | |||||||
Automatic Network Replenishment (ANR) | Support | |||||||
General | ||||||||
Power supply | AC220V±25% | |||||||
Power consumption | Camera 12W, heating 12W, fan 1W, built in LED 10W | |||||||
Dimensions | 530mm×211mm×149mm | |||||||
Weight | 5.96kg | |||||||
Operating environment | -40℃ to 70℃, 10% to 90% RH (non condensing) | |||||||
Lightning and surge protection | Support | |||||||
Ingress protection | IP65 | |||||||
Certification | ||||||||
EMC | CE LVD:IEC 62368-1:2014 | |||||||
Safety | CE EMC:EN 55032:2015+A11:2020+A1:2020 EN 61000-3-3:2013+A1:2019+A2:2021 EN IEC 61000-3-2:2019+A1:2021 EN 50130-4:2011+A1:2014 | |||||||
LPR | ||||||||
Vehicle brand detection | Alfa Romeo, Aston Martin, Audi, Bentley, BMW, BYD, Chevrolet, Citroen, Ferrari, Fiat, Ford, Foton, Golden Dragon, Higer,Hino, Honda, Hyundai, Isuzu, Jaguar, Jeep, Kia, Land Rover, Lexus, Maserati, Maxus, Mazda, McLaren, Mercedes Benz, MG, MINI, Mitsubishi, Nissan, Opel, ORA, Peugeot, Polestar, Porsche, Renault, Rolls Royce, SEAT, SKODA, Smart, SsangYong, Subaru, Suzuki, Tesla, Toyota, Volkswagen, Volvo, Infinti, BAW, Dodge, DongFeng, FEIDIE, KingLong, Everus, Chery, SinoTruk, SAAB, Yutong, Proton, Chrysler, Daihatsu, Datsun, Geely, Hafei, Zotye, Man, Scion | |||||||
Supports multiple countries | North America: USA, Canada Northeast Europe: Slovenia, Poland, Czech Republic, Slovakia, Latvia, Belarus, Ukraine, EU: France, Spain, Portugal, Germany, United Kingdom, Ireland, Bulgaria, Romania, Hungary, Luxembourg, Serbia, Bosnia and Herzegovina, Greece, Croatia, Middle East: Iraq, Saudi Arabia, UAE (Dubai) Southeast Asia: Singapore, Malaysia, Indonesia, Northeast Asia: South Korea, Africa: Egypt |
