| | UPS800-SEA-CEE | UPS800-SEA-UK |
| Capacity |
| Capacity | 800 VA |
| Input |
| Input Voltage | 169 VAC to 278 VAC |
| Input Current | 4 A |
| Rated Input Frequency | 50 Hz / 60 Hz (Adaptive) |
| Output |
| Output Voltage | 198 VAC to 242 VAC |
| Output Current (Mains Supply) | 4 A Max |
| Output Current (Battery Powered) | 50 A Max |
| Output Power (Mains Supply) | 530 W Max |
| Output Power (Battery Powered) | 360 W Max |
| Output Frequency | 50 Hz / 60 Hz (Adaptive) |
| Power Factor | 0.6 |
| Switch Time | <10 ms |
| Output Wave | Pure Sine Wave (Main Electricity Mode); Square Wave (Battery Mode) |
| Battery |
| Built-in Battery | Yes |
| Battery Type | Lead - Acid Battery |
| Qty.of Battery | 12 V, 9 Ah × 1 |
| Charging Current | 0.5 - 4 A |
| Limited Charge Voltage (Boost Charge) | 14.5 V |
| Limited Charge Voltage (Float Charge) | 13.9 V |
| Charging Time | 4-6 hours recover to 90% capacity |
| Status Indicator Light |
| Battery Powered | Middle indicator is flashing red (every 6 seconds) |
| Mains Supply | Left indicator is green |
| Charging while Shutdown | Right indicator is steady yellow |
| Charging while On | Right indicator is yellow with breathing effect |
| Alarm Indicator |
| Low Power | Alarms one sound every 1 second |
| Overload | Alarms one sound every 0.5 seconds |
| Fault | Continuous Alarm |
| Protection |
| Short Circuit | Support |
| Surge | Support |
| Overload | Support |
| Heavy Discharge | Support |
| Overcharge | Support |
| Plugs and Sockets |
| Input Plug | European Standard | British Standard |
| Input Cable Length | 1 m (39.37 ft) |
| Socket | Universal Socket |
| Number of Output Sockets | 2 |
| Structure |
| Product Dimensions | 312 mm * 122 mm * 195 mm (12.3” * 4.4” * 7.7”) |
| Packaging Dimensions | 392 mm * 142 mm * 205 mm (15.4” * 5.6” * 8.1”) |
| Casing Material | Iron and Plastic |
| Appearance Color | Black |
| Net Weight | 5.48 Kg (12.08 lbs) |
| Weight (Battery Only) | 2.44 Kg (5.38 lbs) |
| Environment |
| Operating Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Operating Humidity | 0 to 90% (non-condensing) |
| Storage Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Storage Humidity | 0 to 90% (non-condensing) |
| Certifications |
| Certifications | CE |
