| FC-1GT1GP-20SC(TR)-IN | ||||||||
| 聚合BOM | ||||||||
| 聚合BOM | ||||||||
| Hardware Specification | ||||||||
| Ports Type | 1*10/100/1000M RJ45 port 1*1000M fiber ports port | |||||||
| Wavelength | SM, 1310/1550 nm | |||||||
| Switching capacity | 4Gbps | |||||||
| Forwarding performance | 2.976Mpps | |||||||
| MAC | 2K | |||||||
| Jumbo Frame | 9216bytes | |||||||
| Transmission Distance | 20km | |||||||
| Power Supply | Adapter input voltage : AC 100-240 V Media Converter input voltage: DC 5V | |||||||
| Cooling Fans | 0 | |||||||
| Structure Size | Product Size: 94*70*26mm Package Size: 245*190*60mm Product Net-Weight: 0.2*2kg Product Gross-Weight: 0.7kg | |||||||
| Indicator | PWR(power supply) Lighting: Powered Un-Light: No Power 1000M(Network Link) Lighting: 1000M Link 100M(Network Link) Lighting: 100M Link FX(Optical Link/Act) Lighting: Optical Link ON Flashing: Data transmission Light off: Link disconnect TX(Network Link/Act) Lighting: Link connected Flashing: Data transmission Light off: Link disconnect | |||||||
| Operating Temperature | -20 to 50°C | |||||||
| Operating Humidity | 10% ~ 90%,non-condensing | |||||||
| Storage Temperature | -40°C to 70°C | |||||||
| Storage Humidity | 5% ~ 95%, non-condensing | |||||||
| Packing | ||||||||
| Packing | MEAS: 520*320*400mm Packing Qty: 20 Pair Packing weight: 15 KG | |||||||
