| NSW2010-6T-PoE-IN | ||||||||
| Hardware Specification | ||||||||
| Ports Type | 6×100Mbps network ports (RJ45), including 4 PoE ports | |||||||
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at | |||||||
| Switching capacity | 1.2 Gbps | |||||||
| Forwarding performance | 0.90Mpps | |||||||
| Packet Buffer | 768K bit | |||||||
| MAC | 2K | |||||||
| Weight | <0.6 kg | |||||||
| Dimensions (W×D×H) | 160mm x 93mm x 32mm (6.3"×3.7"×1.3") | |||||||
| Cooling Fans | 0 | |||||||
| Operating humidity | 10%~90% (non-condensing) | |||||||
| Working Mode | Default (Normal mode) : All ports can communicate with each other, EXTEND (Surveillance mode): Transmission distance up to 250 meters | |||||||
| Mean Time Between Failure (MTBF) | > 50000 hours | |||||||
