NSW1010-8GT-IN | ||||||||
Hardware Specification | ||||||||
Ports Type | 8 x 10/100/1000Mbps port (RJ45) | |||||||
Network Media | 10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) 1000Base-TX: Cat5e or higher UTP/STP (≤100m) | |||||||
Switching capacity | 16 Gbps | |||||||
Forwarding performance | 11.9Mpps | |||||||
MAC | 2K | |||||||
Jumbo Frame | 15K | |||||||
Transfer Mode | Store-and-forward | |||||||
Dimensions (W×D×H) | Product: 145*60*21.5mm Packaging: 146*88*50mm | |||||||
Carton Information | Carton dimensions: 530*475*315mm Carton quantity: 100PCS Carton weight: 17.6kg | |||||||
Weight | Product: 0.111kg Packaging: 0.166kg | |||||||
Mount Method | Desktop mount, wall mount | |||||||
Cooling Fans | 0 | |||||||
Operating humidity | 10%~90% (non-condensing) | |||||||
Storage Temperature | -20°C to 70°C | |||||||
Storage Humidity | 5% to 90% RH, noncondensing |
Class | Date | Title | Language | Type | Preview | Download |
Datasheet | 6/20/2025 15:19:48 | UNV NSW1010-8GT-IN Unmanaged Ethernet Switch.pdf | English | Preview | Download A > |
