NSW1010-5T-IN | ||||||||
Hardware Specification | ||||||||
Ports Type | 5 x 10/100Mbps port (RJ45) | |||||||
Switching capacity | 1Gbps | |||||||
MAC | 2K | |||||||
Forwarding performance | 0.744Mpps | |||||||
Standards | IEEE802.3 IEEE802.3u IEEE802.3x IEEE802.3ab | |||||||
Power Supply | DC: 5V 1A, powered by adapter (AC: 100 to 240V) | |||||||
Carton Information | Carton dimensions: 435*280*395mm Carton quantity: 100PCS Carton weight: 14.2kg | |||||||
Mount Method | Desktop mount, wall mount | |||||||
Cooling Fans | 0 | |||||||
Dimensions (W×D×H) | Product: 92*51*21.5mm Packaging: 93*82*51mm | |||||||
Operating Temperature | -10 to 50°C (14°F to 122°F) | |||||||
Operating Humidity | 10% to 90% (noncondensing) | |||||||
Indicator | POWER: Steady on: AC input is normal Off: No AC input LINK/ACT: Off: No link Steady on: Linked Flashing: Transmitting data | |||||||
Weight | Product: 0.062kg Packaging: 0.132kg |
Class | Date | Title | Language | Type | Preview | Download |
Datasheet | 2025/8/8 15:48:05 | UNV NSW1010-5T-IN Unmanaged Ethernet Switch.pdf | English | Preview | Download A > |
