FC-1GT1GP-20SC(TR)-IN | ||||||||
Hardware Specification | ||||||||
Ports Type | 1*10/100/1000M RJ45 port 1*1000M fiber ports port | |||||||
Switching capacity | 4Gbps | |||||||
Forwarding performance | 2.976Mpps | |||||||
MAC | 2K | |||||||
Jumbo Frame | 9216bytes | |||||||
Power Supply | Adapter input voltage : AC 100-240 V Media Converter input voltage: DC 5V | |||||||
Cooling Fans | 0 | |||||||
Indicator | PWR(power supply) Lighting: Powered Un-Light: No Power 1000M(Network Link) Lighting: 1000M Link 100M(Network Link) Lighting: 100M Link FX(Optical Link/Act) Lighting: Optical Link ON Flashing: Data transmission Light off: Link disconnect TX(Network Link/Act) Lighting: Link connected Flashing: Data transmission Light off: Link disconnect | |||||||
Operating Temperature | -20 to 50°C | |||||||
Operating Humidity | 10% ~ 90%,non-condensing | |||||||
Storage Temperature | -40°C to 70°C | |||||||
Storage Humidity | 5% ~ 95%, non-condensing | |||||||
Hardware Specification | ||||||||
Transmission Distance | 20KM | |||||||
Structure Size | Product Size: 94*70*26mm Package Size: 245*190*60mm Product Net-Weight: 0.2*2kg Product Gross-Weight: 0.7kg | |||||||
Packing | ||||||||
Packing | MEAS: 520*320*400mm Packing Qty: 20 Pair Packing weight: 15 KG |
