PKC2641-Z28-P - Uniview - Leader of AIoT Solution

PKC2641-Z28-P

PKC2641-Z28-IR-P

PKC2641-Z80-IR-P

PKC2641-Z80-P

PKC2641-Z100-P

PKC2641-Z100-IR-P

Camera

Sensor

1/1.8-inch 4MP CMOS

Focal length

2.8 to 12mm

8 to 32mm

10 to 50mm

Shutter

Auto, range: 1/200 to 1/100000s

Auto, range: 1/500 to 1/100000s

Minimum illumination

0.0005lux (F1.4)

0.002lux (F1.7)

FOV

Horizontal FOV: 106.4° to 50.3°,
Vertical FOV: 57.1° to 27.8°,
Diagonal FOV: 127.4° to 57.3°

Horizontal FOV: 42° to 15.5°,
Vertical FOV: 23.1° to 8.8°,
Diagonal FOV: 48.5° to 18.3°

Horizontal FOV: 34.3° to 8.7°,
Vertical FOV: 19.9° to 4.8°,
Diagonal FOV: 40.5° to 9.8°

WDR

120 dB

S/N

> 50 dB


Image collection format

2688*1520@60,2688*1520@50,2688*1520@30 (default),2688*1520@25

Frame rate

60, 50, 30 (default), 25, 22, 20, 18, 16, 15, 12.5, 10, 8, 6, 5, 4, 3, 2, 1

Video compression

H.264 (default), H.265

ROI

Supports up to 8 regions

HLC

Support

BLC

Support

Defog

Digital defog

Digital Noise Reduction

3D DNR

Video OSD

Supports 8 overlay areas and allows contents including date, time, date&time, zoom ratio, custom contents

Image OSD

Supports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location

Display Parameters

Resolution

Main stream: 2688*1520, 1080P (default), 720P, D1; Sub stream: 720P (default), D1, 2CIF, CIF; Third stream: D1 (default), 2CIF, CIF

Smart

Application scenario

≤ 30km/h for entrances and exits, ≤ 80km/h for regular roads;
Supports simultaneous application to road and entry/exit scenes without switching

≤ 80km/h for regular roads;
Camera with the focal length of 8 to 32mm can be used for regular roads

≤ 80km/h for regular roads;
Camera with the focal length of 10 to 50mm can be used for regular roads

Vehicle detection mode

Supports video detection

License plate number recognition

Supports recognition of license plates with numbers and letters by default

List configuration

Supports allowlist and blocklist configuration, each list allows 20,000 items
Supports import, export, add, and delete operations

Barrier opening policy

Open barrier only for the recognized vehicles
Open barrier for all vehicles
Open barrier only for vehicles on the allowlist
Open barrier for vehicles not on the blocklist
Configurable Boolean output ID

Storage

Edge storage

Supports ANR with a Micro SD card, up to 512GB

Structure

Illumination

Built-in integrated illumination module, including 4 warm light LEDs, 50m illumination distance, automatic on/off control

Built-in integrated illumination module, including4 IR LEDs, 50m illumination distance, automatic on/off control

Built-in integrated illumination module, including 5 IR LEDs, 50m illumination distance, automatic on/off control

Built-in integrated illumination module, including 5 warm light LEDs, 50m illumination distance, automatic on/off control

Bracket

3-axis mounting bracket

Junction box

The camera comes with a junction box for storing tail cable

Network

Protocols

IGMP,IPv6,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTSP,DNS,DDNS,NTP,UPnP,HTTP,HTTPS,802.1x,SNMP,QoS,SSL/TLS,SSH,IPv4

Compatible Integration

ONVIF (Profile S, Profile G, Profile T),SDK,
API

Interface

Network interface

1×10M/100M RJ45

Serial port

2 × RS485

Boolean output

2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A

Boolean input

2 x input, supports level (up to DC 5V) and switch signal

Audio interface

1 × audio input, 1 × audio output

Storage interface

1 × Micro SD card slot

Reset button

Support

Hardware Specification

Wiegand Interface

Supports Wiegand output

General

Weight

1.87kg

1.91kg

2.02kg

Ingress protection

IP67, IK10

Power supply

DC12V + 25% - 25%
Max. power consumption: 20W
Supports PoE (802.3at, class 4)

Dimensions (L×W×H)

406mm x 126mm x 130mm

Operating environment

-40℃ to 60℃, ≤90% RH

Heater

N/A

Compliance

NDAA Compliant

Support

Certification

EMC

CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 61000-3-3:2013+A1:2019+A2:2021,EN IEC 61000-3-2:2019+A1:2021, EN 50130-4:2011+A1:2014)
FCC(FCC CFR 47 part15 B,ANSI C63.4 2014)

Safety

EN IEC 62368-1:2020+A11:2020
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)

Environment

CE-RoHS (2011/65/EU;(EU)2015/863);WEEE (2012/19/EU)

Protection

IP67(IEC60529:1989+AMD1:1999+AMD2:2013)
IK10(IEC 62262:2002+AMD1:2021)
