| HB-7099-S | ||||||||
| System | ||||||||
| CPU | I7-12650H | |||||||
| Cores | 10 | |||||||
| Threads | 12 | |||||||
| RAM/ROM | 8 + 256 | |||||||
| Operation System | Windows 10 (not activated) | |||||||
| Interface | ||||||||
| USB | 4 × USB 3.0, 2 × USB 2.0, 1 × USB 3.0 Type-C | |||||||
| Audio | 1 × MIC IN, 1 × AUDIO OUT | |||||||
| HDMI | 1 × HDMI | |||||||
| DP | 1 × DP | |||||||
| Network | 1 × RJ45 | |||||||
| Wi-Fi | ||||||||
| Wi-Fi Configuration | WiFi 6 | |||||||
| Bluetooth | ||||||||
| Bluetooth Version | 5.2 | |||||||
| General | ||||||||
| Power Supply | 19 V DC | |||||||
| Product Dimensions (W × H × D) (mm) | 195 × 180 × 30 | |||||||
| Weight (kg) | 1.24 | |||||||
| Operating Temperature | -10°C ~ 50 °C | |||||||
| Operating Humidity | 10%~90% (No Condensation) | |||||||
| Storage Temperature | 20~60℃ | |||||||
| Storage Humidity | 10%~90% (No-condensing) | |||||||
| Class | Date | Title | Language | Type | Preview | Download |
| Datasheet | 2025/12/29 14:29:39 | UNV HB-7099-S I7 Processor Pluggable PC Module(Win10 System is Not Activated).pdf | English | Preview | Download A > |
| Class | Date | Title | Type | Download |
| HD Image | 2025/12/29 3:01:39 | HB-7099-S_HD_Image_1.png | png | Download |
| Class | Date | Title | Download |
| Dimensions | 2025/12/29 3:01:39 | HB-7099-S_Dimensions_1.png | Download |
